Description
Wi-Fi has to be fast, reliable, easy to manage, it must reach every room and every corner. That is exactly what Audience devices can deliver in grand style – even in the biggest houses!
Audience is a tri-band (one 2.4 GHz & two 5 GHz) home access point with meshing technology. If you need Wi-Fi in a huge building with all kinds of obstacles, simply add more Audience devices to your network – with a press of a button they will sync seamlessly and create a single Wi-Fi network to cover the whole premises. The initial setup is also very simple – download the iOS or Android MikroTik app, it will connect to the router and guide you through a quick setup process.
In some cases a single Audience unit might be able to replace several other routers – in our tests it covered 1858 m² (20000 square feet) easily. It depends on the amount of obstacles, Wi-Fi clients and interference, so results may vary.
Dual-chain 2.4 GHz and 5 GHz wireless coverage will solve most interference issues in a crowded environment. For example, you can simultaneously use the 2.4 GHz channel for all your household mobile devices and reserve the 5 GHz channel for your PC or TV.
Order your Audience today and start living in the future. The future of easy and elegant networking.
Specifications
Details |
Product code |
RBD25G-5HPacQD2HPnD |
Architecture |
ARM 32bit |
CPU |
IPQ-4019 |
CPU core count |
4 |
CPU nominal frequency |
716 MHz |
License level |
4 |
Size of RAM |
256 MB |
Storage size |
128 MB |
Storage type |
NAND |
Tested ambient temperature |
-40°C to 60°C |
Suggested price |
$169.00 |
Powering
Details |
PoE in |
Passive PoE |
PoE in input Voltage |
24-57 V |
Number of DC inputs |
2 (PoE-IN, DC jack) |
DC jack input Voltage |
12-57 V |
Max power consumption |
27 W |
Max power consumption without attachments |
27 W |
Wireless
Details |
Antenna gain dBi for 2.4 GHz |
3.5 |
Wireless 2.4 GHz standards |
802.11b/g/n |
Wireless 2.4 GHz Max data rate |
300 Mbit/s |
Wireless 2.4 GHz number of chains |
2 |
Wireless 2.4 GHz chip model |
IPQ-4019 |
Wireless 5 GHz Max data rate |
867 Mbit/s |
Wireless 5 GHz number of chains |
2 |
Wireless 5 GHz standards |
802.11a/n/ac |
Antenna gain dBi for 5 GHz |
4.5 |
Wireless 5 GHz chip model |
IPQ-4019 |
Wireless 5 GHz Max data rate |
1733 Mbit/s |
Wireless 5 GHz number of chains |
4 |
Wireless 5 GHz standards |
802.11a/n/ac |
Antenna gain dBi for 5 GHz |
4.5 |
Wireless 5 GHz chip model |
QCA9984 |
Wi-Fi generation |
5 |
Ethernet
Details |
10/100/1000 Ethernet ports |
2 |
Other
Wireless specifications
2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
1MBit/s |
26 |
-100 |
11MBit/s |
26 |
-94 |
6MBit/s |
29 |
-96 |
54MBit/s |
26 |
-80 |
MCS0 |
29 |
-96 |
MCS7 |
25 |
-75 |
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
6MBit/s |
28 |
-95 |
54MBit/s |
25 |
-78 |
MCS0 |
28 |
-95 |
MCS7 |
24 |
-75 |
MCS9 |
22 |
-70 |
5 GHz |
Transmit (dBm) |
Receive Sensitivity |
6MBit/s |
32 |
-96 |
54MBit/s |
28 |
-80 |
MCS0 |
32 |
-96 |
MCS7 |
27 |
-77 |
MCS9 |
25 |
-72 |
Included parts
