Description
The new, completely waterproof, rugged, and super high powered RouterBOARD Metal. The serious outdoor wireless device. Now in 2.4Ghz with amazing high TX power!
Fully sealed, industrial design metal case, powered by RouterBOARD and RouterOS. High output power – to reach the last mile, in any conditions. It comes with L4 license, so you can attach your favorite antennna to use it as an AP, to make wireless point-to-point links or as a CPE- whatever you prefer! Works in the 2GHz frequency (2192-2732MHz depending on country regulations)
It has a built-in N-male connector, and pole attachment points, so you can attach it to an antenna directly, or use a standard antenna cable. LED signal indicators make it easy to install and align.
Package contains Metal-2SHPn, mounting loops, PoE injector, power adapter and 6dBi omni antenna
Specifications
| Details | |
|---|---|
| Product code | RBMetal2SHPn |
| Architecture | MIPSBE |
| CPU | AR7241 |
| CPU core count | 1 |
| CPU nominal frequency | 400 MHz |
| Dimensions | 177x44x44mm, 193g |
| License level | 4 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Tested ambient temperature | -40°C to 70°C |
| Suggested price | $99.00 |
Powering
| Details | |
|---|---|
| PoE in | Passive PoE |
| PoE in input Voltage | 10-30 V |
| Number of DC inputs | 1 (PoE-IN) |
| Max power consumption | 13.8 W |
Wireless
| Details | |
|---|---|
| Wireless 2.4 GHz number of chains | 1 |
Ethernet
| Details | |
|---|---|
| 10/100 Ethernet ports | 1 |
Other
| Details | |
|---|---|
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 32 | -93 |
| 54MBit/s | 27 | -77 |
| MCS0 | 32 | -92 |
//
/* */
